The series tax-controlled fuel dispenser is compact, easy to install, and ideal for use in units and mobile gas stations. It offers high cost-effectiveness and flexible configuration, with options for gear pumps, combined pumps, and submersible pumps. The large LCD screen provides clear digital display. Flow rate options include 50L, 80L, and 100L. Key technical parameters include an operating temperature range of -25°C to +55°C, relative humidity ≤95%, standard flow rate of 5-50L/min, maximum permissible error of ±0.30%, noise <80dB(A), and inlet vacuum ≥54Kpa. Power supply options are AC220V or AC380V with ±10% tolerance, 50Hz. The unit is equipped with an explosion-proof motor (0.75KW/1KW). The minimum measured volume is 5 liters. Price setting range is 0.00~99.99 yuan/L, single metering cumulative volume range is 0~9999.99L, and preset range is 1~9999L or 0~9999 yuan. For installation, the horizontal distance between the dispenser and the underground tank should generally not exceed 50M, and the vertical distance from the lowest point of the tank to the dispenser inlet should not exceed 5M. Installation must comply with relevant fire safety and design codes. If using an above-ground tank or if the oil level exceeds the oil-gas separator, the separator vent must be sealed. The dispenser should be installed in a rainproof and sun-proof environment, with sand filling around the inlet pipe and cable conduit.
